Moulded Case Circuit Breaker (MCCB)
Moulded Case Circuit Breaker (MCCB)
Axiom Controls manufactures the Ax1 & Ax1e Moulded Case Circuit Breaker (MCCB) series. An MCCB is an advanced version of the miniature circuit breaker — an automatic electrical device that forms the core element of the LV switchgear power-distribution system and protects the low-voltage distribution system against short circuits.
Fixed thermal and magnetic settings provide overload, short-circuit and under-voltage protection: the thermal mechanism handles overload while the magnetic mechanism handles short circuit. A movable trip unit gives fast switching during fault current, with a remote ON/OFF feature, adjustable trip settings and a compact design that handles much higher currents than standard MCBs — making it suited to heavy-duty applications.
Key features
- Fixed thermal and magnetic settings (overload, short-circuit, under-voltage)
- Movable trip unit with fast fault switching
- Remote ON/OFF operation
- Adjustable trip settings
- Higher current handling capacity than MCBs
- Compact moulded, flame-retardant case
Technical specifications
| Specification | Details |
|---|---|
| Models | AX1e-100, AX1-125, AX1-250, AX1-400, AX1-630 |
| Rated insulation voltage | AC 800V |
| Rated working voltages | AC 415V, AC 690V |
| Operating voltage range | 40V to 400V |
| Pole configurations | 3-pole or 4-pole |
| Breaking-capacity grades | L, M, H |
| Limit short-circuit breaking capacity | 35–100 kA |
Recommended applications
Main incomers and sub-distribution in commercial and residential buildings and heavy industrial areas handling very high currents.
Frequently asked questions
MCCBs handle much higher currents and offer adjustable trip settings, making them suited to main incomers and sub-distribution rather than final circuits.
Yes, Axiom MCCBs offer adjustable thermal-magnetic settings to match the protected circuit.
They protect main and sub-main circuits in commercial, residential and heavy industrial installations.
